Activations in Spain continued

Thanks to the efforts of Guru EA2IF and Ignacio EA2BD I was able to activate more summits in Spain together with Juan EA1AER. Juan met me on the 21st of September, a Saturday in Léon, a very beautiful, historic city. Then he came back on 23rd Sept to take me for a trip out into some beautiful country north east of Leon.

The summits we went to were EA1/LE-197 and EA1/LE-165. These are north east of Leon requiring about two hours drive to reach the first.

The first required a good climb to reach the summit. From where the car was parked I actually doubted that it was possible to reach the activation zone. It looked steep and narrow. However I thought Juan had activated this in the past and assumed this was a well known summit. The climb started out as a mild stroll up a forest path then up some steps formed with wooden risers. I climbed up the lower sections quite easily, having just walked for almost 500 km in the previous 3 weeks.

Then it became a steep climb up earth and rock steps with a chain on the left for assistance. This was slower!

At the top the view was breathtaking. I could see the road but not the car as it was obscured by trees. It all looked a long way down. My photos probably don’t show it well enough.

The first few photos are mine. Then I have added some of Juan’s photos.

Some photos from Juan’s website are copied here too.

After erecting the end fed 20m wire it was tuned for best output power on the 817 and I called CQ on 20m Cw. Contacts flowed quickly. Then Juan made more contacts.

Finally we packed up and ate some lunch. Just as we were preparing to start the descent I received a message from Ignacio EA2BD asking if we were still on the air. I had to say no, as everything had been packed away. Disappointing as I would have liked to give him a new summit unique.

Juan remarked that I would be the first activator of the summit. I then realised that my earlier assumption was incorrect. It had not been activated before and it was the first time Juan had been there.

Juan then showed me some more of the sights in the valleys of this area.

We then went to another summit but the contacts made from this one didn’t qualify for SOTA.

This activation is also described on Juan’s blog at: https://ea1aer.blogspot.com/2019/09/con-vk1da-en-pica-de-ten.html which is written in Spanish (use Chrome browser for an approximate translation).

Here is a photo of most of the group of Leon hams who met us on the second summit, partly to meet me and partly to visit the club’s repeater site.

SOTA activations in Spain (3)

The next day after arriving in Pamplona and the activation with Guru EA2IF arrangements were made for another activation which would be NV-119 San Cristobal. This activation was made with Ignacio EA2BD. He had already activated this summit during this year.

The antenna, one I had borrowed from Andrew VK1AD, was a LNR EFHW and was setup as an end fed half wave for 20m.

With the antenna fed directly from the KX3 it was showing a SWR or 2.5 so I put the Elecraft T1 into the circuit, producing a 1.0 swr for the kx3.

This setup enabled me to make a number of contacts on both cw and SSB, on 20m. As it was the middle of the day we did not expect any dx and there was no signal from the USA or further afield.

Ignacio and I pose for the selfie

Yes I’m having fun…

I record here my sincere appreciation of the effort made by Ignacio to help me with this activation, also he drove twice to Roncesvalles, the second time was to retrieve the logging tablet which I accidentally left at the Bar there.

After the activation I was invited to join Ignacio and his wife and daughter for lunch at their apartment. This was a very pleasant occasion for me and I felt very honoured to be a guest in their home.

Thanks again, Ignacio EA2BD.

SOTA activations in Spain (2)

After reaching Pamplona and finding a hotel for some welcome relative luxury compared with the 8-16 double bunks in the bedrooms of hostels (typical of the low cost accommodation on the Camino) I had arranged to meet Guru EA2IF so we could activate a nearby summit,  Mt. Erreniega EA2/NV-092.

In fact he parked near my hotel and I easily found him when I left the front door. He was nearby and waving to me. So we set off towards the summit, chatting about SOTA, radios, antennas etc as radio hams do.

Arriving at the summit it was easy to set up the antenna and the FT817 with atu for 20m. Conditions were not as good as they had been three days earlier, but I made more than enough contacts to qualify the summit. As I had worked Ignacio EA2BD at this summit in 2018 this activation made this summit a “complete” (ie. worked and activated).

Guru was trying to make contacts using an economy HT on 439 MHz. There were no replies.

In an attempt to let him make at least one valid contact on 439 fm we walked down the hill far enough to be out of the activation zone. Guru returned to the top and called me using the ft817. I could hear the signal from the FT817 but the HT was transmitting so little power that the reverse path did not work. I walked back up the hill and was within 10m of the other radio before the HT was heard. Clearly a fault in the transmitter.

On the way down we passed the Alto Perdon with its monument to pilgrims and Guru told me I would pass that on my way out of Pamplona on Monday. You can find my pictures of the monument etc on my walking blog. Https://Walkdontrun.travel.blog. Look for the post about departing from Pamplona, day 7.

We then visited the site of a contest station owned by local hams and I admired the rotary antennas etc. then we went to his home for a short time, then to a local club for a meal and of course a longer chat about the same subjects.

I first contacted Guru about the possibility of activations in this area. Thanks to Guru not only for the advice but the hospitality and for taking me up for those activations.

The feedpoint for the EFHW used on hf
Guru setting up the uhf antenna

Evidence of my presence on the hilltop

More evidence

SOTA activations in Spain (1)

While planning a visit to Spain to walk the Camino Frances or the French Way, a popular walking route following the legendary path of pilgrims walking to Santiago for religious reasons, I made contact with two radio amateurs in Pamplona to ask about suitable SOTA activations in that area. I received enthusiastic responses and offers to take me up to several suitable summits.

I set up a WhatsApp chat group to make liaison simpler once I was in the area. I pre-purchased a European SIM card for my phone to be sure of having local coverage.

The first summit I was hoping to activate was ea2/nv012 with the amazing name Ortzanzurieta which is a basque name with very difficult pronounciation for an Aussie. I had several goes at it. The Z is not said as it is in English.

This summit was a few km to the east of the walking path (Camino) and I asked my EA contacts whether I could consider activating it during the day’s walk. I received advice that it would be a big ask at the end of a difficult day. The Camino goes through some lovely country especially in those mountains but it is not “a walk in the park”. There are some long slow climbs for weary legs.

However Ignacio EA2BD offered to drive from Roncesvalles and take me up to this summit. I took up his offer immediately.

After walking about 17km from Orisson, over the Pyrenees and the F/EA border, I could only agree with the advice. I was tired and needed a shower and fresh clothes before I could consider getting into a clean car.

So by about 5pm that day I was happily riding with Ignacio and Jorge EA2LU on the way up to this unpronounceable summit. The weather was suitable and although I had my radio gear with me, Jorge offered me the use of his kx2 and multiband end fed antenna.

The 20m band was cooperating and I made 28 contacts around Europe and into the US.

VK1DA and EA2LU Jorge setting up next to the trig

Ignacio Ea2bd Jorge EA2LU and me

After a long day of walking I made lots of mistakes sending cw but I was having fun

Jorge using another rig on 40m

All photos by Ignacio Ea2bd.

Many thanks to Ignacio for his generosity in driving over from Pamplona and waiting patiently for me to be ready for this activation. It was a huge day for me and adding a new SOTA association and summit to my activations was a bonus.

South Black Range SOTA and park activation on 13cm band – 15th June 2019

Having received an offer from Ted VK1BL to help me find and fix the problem in my 13cm transverter, I spent an evening with him on 13th June. Moving through the various functional blocks in the transverter we found

  • The receiver was working quite ok, it was very close to the right frequency and was fairly sensitive, hearing -120 dbm from the HP sig gen pretty well
  • The output from the PLO was good and at a level of +7 dbm as recommended for the mixer
  • The output from the sequencer board, which includes attenuators and a level setting control for the IF signal, 144 MHz in this case, was working well and we calibrated that at -10 dbm for input to the mixer, with 0.5w drive on 144 mhz from the ft817
  • The output from the mixer and filter was at the expected level, about -13 dbm
  • The output from the tx IF amplifier/driver was +10 dbm, which was adequate for the power amplifier
  • The power amplifier had the correct negative bias and positive voltage on the correct terminals
  • But the power output to the antenna socket was zero.
  • The power output from the amplifier (before the relay) was about +35 dbm (approx 2.5 watts)
  • The relay board was examined and was found that the DC to the relay coil was intermittent. Resoldering the pins of the relay, a surface mount type, fixed that intermittent and made it a reliable connection. The output to the antenna socket was then +35dbm or 2.5w.
  • Transverter considered fixed.

With that result I discussed the possibility of an activation on Saturday morning to prove it in the field. Andrew VK1AD offered to activate Mt Stromlo and I decided to visit South Black Range. Coincidentally it was the day when bonus points commenced for VK2 summits above 1200m, so I half expected to find some snow on the higher parts of this summit, as it had recently snowed down to about 900m.

No snow, quite cold at about 3 or 4C when I got there, but it warmed up to about 8C by midday.

FT817 in foreground, transverters and tripod holding 1296 yagi at rear

After initial contacts on 144 then 1296 we switched over to 2403 MHz and found we were able to make easy contact, my signal received a 5×8 report from VK1AD and I received his signal at an indicated strength 5.

Note: the distance of this contact was about 47.5 km, not bad for 2.5 watt transmitters. The locators of the two summits are QF44MQ (Stromlo) and QF44SN. The visual horizon is 35km so this is beyond “line of sight”. But how far over line of sight is it?

According to my iphone app DistBear the distance between centres of the two grid subsquares is 47.5km. So 2.4 GHz worked fine, well over the visual horizon. To get a more accurate distance I used the website https://sotamaps.org, using the “range mapping” option, we get a more accurate measure of the distance, at 48.7 km. I am sure there will be longer contacts made on this band using the same equipment.

The antenna in use for 2.4 GHz at my end is shown in the photo below attached directly to the 2.4 ghz transverter, was the SG-LAB PCB antenna, a 2 element HB9CV type on loan from Andrew VK1AD. The 2403 MHZ equipment was placed on a rock and turned so that the antenna pointed roughly towards Mt Stromlo, albeit through many trees nearby.

Two UHF transverters
The SG Lab transverter for 1296 is shown here sitting on the box containing the home made transverter for 2.4 ghz. These two transverters are, ironically, equivalent in power output and receiver function though they operate on different bands.

After completing the contact on 2.4 GHz I moved to HF and ran a few contacts on 7023 khz using the Pixie half watt morse transceiver (on a 50 x 50 mm PCB), then moved to the KX3 and ran contacts on 40m and 80m SSB and CW. I left the summit just after 12 noon, after spending 2 hours there. The temperature had risen to 8C by then.

Pixie PCB transceiver, battery, key, ATU, balun

Qualifying a summit – making 4 interstate contacts – using the 500 milliwatt Pixie morse transceiver

I built up the Pixie kit, having bought it a year ago or more, just to see how it worked and intended to try it out on a SOTA activation.

Being invited to accompany Andrew VK1AD to Mt Marulan for a return visit, having done the same in December 2018, I decided to take the Pixie along to see if it could make even one contact with 40m conditions as dicey as they are at present.

I set up the station to use the Pixie, with the ZS6BKW doublet fed through an Elecraft T1 tuner and the choke balun recently built. (Did I write about that? Maybe not.)

I listened for a minute or two on the Pixie’s 7023 khz and could hear VK2ARZ calling CQ with a very high offset frequency, my guess was that he was on 7025 so would not hear me operating on 7023. The Pixie’s receiver is a direct conversion receiver without any inherent selectivity so if my ears had 10 khz frequency response I would have heard stations out to that offset in both directions, ie. higher and lower in actual frequency, eg. A signal on 7013 would produce a 10 khz frequency difference so the 10 khz would be coming through the receiver, as would a 7033 khz signal also produce a 10 khz audio frequency. My 69 year old ears don’t have that bandwidth any more, they have an inbuilt low pass filter.  🙂

So I spotted myself on Sotawatch using the vk port-a-log software on the android tablet, called CQ using the little blue hand key, listened, then called again. A big signal loomed in the earbuds and it sounded like a bug being used. Was it Steve VK7CW, yes, it certainly was, after the call letters marched across my ears and I logged the contact using the tablet. What strength was he? I didn’t know, sounded pretty good so I gave him 579. Received 559 in reply, not bad for half a watt. Steve said he was running an FT817 at 5 watts out. Monster power.

Three more contacts, regulars John VK4TJ in Toowoomba, Peter VK3PF in Churchill Victoria, and finally Paul VK3HN from Melbourne made it into the Pixie log and I’d qualified the summit in 11 minutes using a Pixie half watt, two transistor + one IC transceiver, that had cost me $9 for the kit.

In between the contacts I could hear some weak signals and I wondered how strong they were, perhaps they were others who I wasn’t hearing well enough to copy. So after completing the 4th contact and calling another CQ just to be sure I had worked all who were there, I transferred the antenna to the KX3 and had a better listen to the weak signals. They were weak on that radio too, and I think they were dx stations, probably US operators in a contest of some kind.

Pixie 500 mw transceiver as built above, and as used, below
L-R: Elecraft T1 tuner top left, Pixie PCB, 3S LIPO battery, cwmorse.us hand key. The Pixie board is about 2″ x 2″ or 50mm sq.

The rest of the activation was fairly straightforward using the KX3 and the same doublet antenna, some contacts on 80m, most on 40m, the Shires contest was running so I had to look up my shire, I quoted GM2 (Goulburn Mulwaree) so I hoped that was correct.

Three summits between Wee Jasper and Tumorrama on 2nd June 2019

With benign early winter weather, cool mornings but calm clear days, it was clearly the right weather for activating summits.

The first was Mt Wee Jasper. It is on a famous walking track known as the Hume and Hovell walking trail. It can be accessed from the camping area south of the Wee Jasper village, but the walk is long and recent forestry work has apparently disrupted the trail. At 7+ km it would have taken too much time out of the day too. So my access route was to first head west on the Wee Jasper-Tumut road, then southwards on the Wee Jasper forest road by a few km. Turning off onto Pheasant Creek Rd, the mountain looms into view soon and the route to the parking area is fairly obvious though the road has been cleared of any gravel and may well be soft after heavy rain.

It is a pleasant and easy walk of about 15 minutes up the forest path to the summit, where there are two concrete-and-wood benches ideal as sitting and operating radios.

I deployed the zs6bkw doublet for hf with the kx3. For 1296 the ft 817 and the transverter were connected to the 4 el yagi mounted on the camera tripod. The icom v85 was used to make some contacts into Canberra on 2m fm. No available contacts for 1296 but the Canberra beacon from Mt Ginini was very strong. On hf it was easy enough to make contacts on 40 and 80m bands using ssb and cw. I aim to “qualify” each summit on both ssb and cw. It is also satisfying to make the required 4 contacts to “qualify” on each band, though this is a personal goal rather than any external requirement.

IMG_4086_S
Track marker for Hume & Hovell walking track on the edge of the forest at Mt Wee Jasper
IMGP0068_S
UHF gear on the park bench
IMGP0069_S
The 1296 beam on the camera tripod at Mt Wee Jasper
IMGP0070_S
HF gear on the other side of the bench

You may have read that wombats leave a rather uniquely shaped message on the ground.  Here are a few I stepped over on my way up Mt Wee Jasper.  Each “cube” is about a cubic inch.  How they shape them like that is a matter others can deal with.

IMGP0067_S

Despite the pleasant forest environment it was time to depart after an hour on summit, then pack away and head for the car. I had looked at the navigation options for reaching the next summit and concluded that the known roads were a more reliable option than trying to find shortcuts. So southwards on Wee Jasper forest road to Brindabella rd, east for a few km, then turning northeast along Nottingham Rd. About 15 km along this road is the parking point for Snowgum Mt. There is no public car access up to the summit so requires a steepish walk up a sealed road littered with leaves and twigs from the eucalyptus trees.

Setting up the gear again I heard signs that Andrew vk1ad was ready at Mt Stromlo for the planned s2s contacts including 1296 ssb. Hearing his voice weakly at first, I experimented with the position and direction of my antenna, peaking the signal in the expected direction. When his contact with a Canberra station ended, I called him and received a question as to who was calling. I moved to cw mode and sent a 20-30 second string of dots using that mode, to allow him to find the best antenna direction by setting it for the maximum signal. Dots are very good for this purpose as they have a constant average signal strength but are transmitted at maximum power, much stronger than voice signals with an average power of less than 30% of maximum. His reply came much stronger than the level I had previously heard. In fact over the next 5 minutes, signal strengths gradually increased to about 8 on the ft817 “blobometer”. (It isn’t a real meter, just blobs being lit up on the lcd display. )

Several additional contacts were then made on 2m fm, starting with Wade vk1mic, Matt VK1MA, then Dean VK1DW and I could hear Dermy VK1FDHA calling me but he was not hearing me on any of the antennas he tried. I also heard Peter vk1fphr calling but he also didn’t hear my replies.

At this point it was approaching 2pm and I knew that if I didn’t leave soon for my next summit, my departure from that summit would be in darkness. So I didn’t set up the hf antenna on this summit, failing to meet my goal of “qualifying” on several hf bands and also on cw. A return visit this year may be necessary.

I reached the next summit just on one hour after my planned activation time, sunset was at about 5 pm so I needed to get the contacts in the log. A few contacts were made with Wade and Matt over in Canberra on 2m fm but the rest of the activity was on 80m ssb and cw. I went to 40m but made only a couple of contacts on that band. Propagation conditions near sunset make distances below about 800 km quite difficult on that band. I was using my phone to log the contacts, as i could not find my logging tablet when I unpacked my gear on this summit. Had I left it in the car? Or had I packed up so quickly at Snowgum Mt that I had left the tablet there? It turned out that I hadn’t left it in the car at all, more of that to come.

I would have to go to my backup logging technology, paper and pen. That posed a small problem because although I had a notebook there was no pen in my pack or in the accessories box. Then I remembered that I had been intending to test the logging functions in the ParksnPeaks ios app on my iPhone. So, logging on this site was done using the ParksnPeaks app on the iPhone and it did it very well. The test version I had was working well.

It was then coincidental and somewhat ironic that when I went to 40m I was called by Sue vk5ayl, the developer of the ParksnPeaks app. We had a good chat and I mentioned that i was using the app for logging.

But the light was fading and I had to get out of the forest before darkness made it difficult. So I called it quits at about 5pm, packed up and found my way back to the car.

Approaching the car, I was surprised but relieved to find my logging tablet on the ground behind it. Thinking back to when I had prepared for the activation, removing the ft817, 1296 transverter and tripod from the pack, I must have dislodged the tablet and failed to put it back into the pack. Another reminder of how important it is to look around before departing.

It was now almost dark and I did not want to drive back through the Wee Jasper forest, it is the time of day when kangaroos and wallabies move around in search of food. So I drove west to Tumut, stopped at the Oriental Hotel for dinner, then drove to Gundagai and back to Yass along the Hume highway. The highway is also named after the early explorer whose name was given to the walking track mentioned earlier.

On the way I crossed this bridge with a unique name, I couldn’t resist stopping to take a photo of the bridge sign.  The bogs must shake a lot in that area.

IMG_4098c_S

Three summits, 18 activator points and some s2s points for the summit-to-summit contacts made. And a good meal at the Oriental.
